Correa Axia Milling Machines

The AXIA represents a pure box-in-box concept, combining an innovative ram droop mechanical system with a unique ram guiding system.

Longitudinal X axis: 4.000 - 25.000 m

Automatic Universal Head

Cross Y axis: 1.250 / 1.500 m

Numerical control Heidenhain or Siemens (Operate HMI)

Vertical Z axis: 1,500 / 2,000 / 2,300 / 2,500 / 3,000 m

Portable handwheel

Air-conditioned electrical cabinet

Linear guides in the X, Y and Z axes

Lamp in the working area

Hydraulic and cooling group

Linear scales in all axes

External Coolant with adjustable nozzles in the head

Internal and external air flow

Tele-service

Guarding

Programmable Speed: 6,000 - 6,000 - 10,000 rpm

Max Power: 33 - 43 - 42 kW
