Correa Fenix Travelling Column Milling Machine

The FENIX represents a new concept of travelling column machine with lateral ram.

Benefits of the Correa Fenix Travelling Column Machines

Highly robust based on a system of L-guided ram. High precision thanks to the mechanical system of ram droop correction. A flexible machine appropriate for roughing and finishing operations.

Longitudinal X axis 4.000 - 25.000 m
Automatic Universal Head
Cross Y axis 1.250 / 1.500 m
Numerical control Heidenhain or Siemens (Operate HMI)
Vertical Z axis 1.500 / 2.300 m
Portable handwheel
Air-conditioned electrical cabinet
Linear guides in the X, Y and Z axes
Lamp in the working area
Hydraulic and cooling group
Absolute Heidenhain measurement rules in all axes
Exterior coolant with adjustable lance nozzles
Internal and external air flow
